| Material | Carbon Steel |
| Grade | ASTM A105 / ASTM A105 / ASME SA105 |
| Standard | ASTM A105 / ASME SA105 |
| Type | Weld Neck Flange |
| Size Range | NPS ½" – 24" (DN 15 – DN 600) |
| Pressure Class | 150# – 2500# (ASME B16.5) |
| Facing | RF / FF / RTJ |
| Dimensional Std | ASME B16.5 / B16.47 |
| Tensile Strength | 485 MPa min |
| Yield Strength | 250 MPa min |
| MTC | EN 10204 3.1 Mill Test Certificate |
| MOQ | 100 kg (standard sizes) |
Quick Answers
ASTM A105 Weld Neck Flange – Overview
ASTM A105 is a carbon steel forging grade for flanges, fittings and valves in ambient- and high-temperature pressure service. Its balanced strength and weldability make it the most widely specified fitting material in oil & gas and power plant piping.
BB Infras is a leading ASTM A105 Weld Neck Flange supplier, stockist and exporter based in Mumbai, India. We maintain ready stock across popular sizes and schedules, backed by full traceability with EN 10204 3.1 Mill Test Certificates. ASTM A105 Weld Neck Flange is available in pressure classes 150# to 2500# per ASME B16.5 / B16.47, with raised face (RF), flat face (FF) or ring type joint (RTJ) facing options. Custom bore and custom OD flanges are available on order.
Need a quote for ASTM A105 Weld Neck Flange?
Our sales team responds within 2 business hours with price & availability.
Request Quote WhatsAppChemical Composition of ASTM A105
The following table shows the chemical composition per ASTM A105 / ASME SA105.
| C | Mn | Si | P | S | Cu | Ni | Cr | Mo | V |
|---|---|---|---|---|---|---|---|---|---|
| ≤ 0.35 | 0.60–1.05 | 0.10–0.35 | ≤ 0.035 | ≤ 0.040 | ≤ 0.40 | ≤ 0.40 | ≤ 0.30 | ≤ 0.12 | ≤ 0.05 |
Mechanical Properties of ASTM A105
| Property | Value |
|---|---|
| Tensile Strength | 485 MPa min |
| Yield Strength | 250 MPa min |
| Elongation | 22% min |
| Reduction of Area | 30% min |
| Hardness | 187 HB max |
Physical & Thermal Properties
| Property | Value |
|---|---|
| Density | 7.85 g/cm³ |
| Melting Point | 1425–1540 °C |
| Thermal Conductivity | 51.9 W/m·K |
| Thermal Expansion | 11.7 × 10⁻⁶ /°C |
| Elastic Modulus | 200 GPa |
| Specific Heat | 486 J/kg·K |
| Electrical Resistivity | 0.170 μΩ·m |
Equivalent Grades of ASTM A105
| Standard Body | Equivalent Grade |
|---|---|
| ASTM/ASME | A105/SA105 |
| EN/DIN | C22.8 / 1.0460 |
| UNS | K03504 |
| BS | 1503-221 |
| JIS | SFVC1 |
| IS | IC 28 |
Weld Neck Flange – Product Details
Applicable Standards: ASME B16.5, ASME B16.47, EN 1092-1, DIN 2633
Manufacturing Process: Forged from billet; machined face; bore matched to pipe ID; hub taper machined.
Heat Treatment: Normalize 870–940 °C, air cool. Stress relief 595–650 °C optional.
ASTM A105 Weld Neck Flange – Manufacturing Process
Weld Neck Flange is produced using a controlled sequence of operations to achieve the dimensional and mechanical requirements of ASTM A105 / ASME SA105.
1050–1200 °C
Normalise / Q&T
Face & bore
Per ASME B16.5
ASTM A105 Weld Neck Flange – Sizes & Dimensions
Size range: NPS ½" – 24" (DN 15 – DN 600). The following dimensional data covers standard sizes. Non-standard sizes available on request.
| NPS | OD (mm) | Bolt Circle (mm) | No. Bolts | Bolt Dia |
|---|---|---|---|---|
| ½" | 95 | 66.5 | 4 | M12 |
| 1" | 125 | 85 | 4 | M12 |
| 2" | 165 | 127 | 4 | M16 |
| 4" | 254 | 200 | 8 | M16 |
| 6" | 318 | 269 | 8 | M20 |
| 8" | 381 | 330 | 8 | M20 |
| 12" | 520 | 451 | 12 | M24 |
Types of ASTM A105 Weld Neck Flange
- 150# WN Flange
- 300# WN Flange
- 600# WN Flange
- 900# WN Flange
- 1500# WN Flange
- 2500# WN Flange
Applications of ASTM A105 Weld Neck Flange
Industries We Serve
Ready to order ASTM A105 Weld Neck Flange?
Stock available in Mumbai. Same-day quotation. Export documentation included.
Email Quote Call NowASTM A105 – Grade Specification
| Standard | Category | Tensile Strength | Yield Strength | Elongation |
|---|---|---|---|---|
| ASTM A105 / ASME SA105 ✓ | Carbon Steel | 485 MPa min | 250 MPa min | 22% min |
| ASTM/ASME (A105/SA105) | Equivalent | See equivalent grades table above | ||
| EN/DIN (C22.8 / 1.0460) | Equivalent | See equivalent grades table above | ||
| UNS (K03504) | Equivalent | See equivalent grades table above | ||
| BS (1503-221) | Equivalent | See equivalent grades table above | ||
| JIS (SFVC1) | Equivalent | See equivalent grades table above | ||
| IS (IC 28) | Equivalent | See equivalent grades table above | ||
* All values are minimum guaranteed per ASTM A105 / ASME SA105. Actual mill certificates may show higher values.
Why Buy ASTM A105 Weld Neck Flange from BB Infras?
| Ready Stock | Large inventory of ASTM A105 Weld Neck Flange in popular sizes maintained in our Mumbai warehouse for immediate dispatch. |
| Certified Material | All material supplied with EN 10204 3.1 Mill Test Certificates from NABL-accredited labs. TPI by SGS, BV, TUV on request. |
| Worldwide Export | We export ASTM A105 Weld Neck Flange to 80+ countries with complete export documentation — COO, packing list, B/L, fumigation certificates. |
| Competitive Pricing | Direct mill sourcing and bulk buying ensures competitive prices. No middlemen. Transparent pricing with no hidden charges. |
| Fast Delivery | Standard sizes dispatched within 3–5 business days. Custom sizes within 3–4 weeks. Urgent orders accommodated. |
| Value-Added Services | Cut-to-length, bevelling, threading, galvanising, painting, marking & stencilling available in-house. |
| Technical Support | Our metallurgical team assists with grade selection, standard interpretation, and material substitution queries. |
| MSME Registered | Registered MSME supplier. Eligible for GeM portal procurement and government tenders. |
Certifications & Quality Inspection
Every ASTM A105 Weld Neck Flange supplied by BB Infras undergoes the following quality controls:
Quality Inspection Checklist
- Chemical composition analysis (OES / wet analysis)
- Mechanical testing: tensile, yield, elongation, impact
- Dimensional inspection per applicable ASME standard
- Visual and surface finish inspection
- Hydrostatic or pneumatic pressure testing
- Non-Destructive Testing: UT, RT, MT, PT on request
- Positive Material Identification (PMI) on request
Export Packaging & MOQ
- Minimum Order Quantity (MOQ): 100 kg or 1 piece (standard sizes); 500 kg for custom sizes
- Packing for Pipes/Tubes: Bundled with steel strapping, plastic end caps, moisture-proof wrapping
- Packing for Fittings/Flanges: Wooden box / wooden pallet, plywood case for heavy items
- Sea Freight: FCL / LCL container, fumigation certificate provided
- Air Freight: Available for urgent requirements
- Documents: Commercial Invoice, Packing List, Certificate of Origin, MTC, Bill of Lading, Insurance Certificate
- Marking: Heat number, grade, size, schedule, standard per ASTM A5.40 / ASME marking requirements
Weld Neck Flange Marking & Identification
Every ASTM A105 Weld Neck Flange supplied by BB Infras is marked per ASTM A105 / ASME SA105 and ASME marking requirements. Standard marking sequence:
- Manufacturer name / mark
- Material specification — ASTM A105
- Pressure class — 150# / 300# / etc.
- NPS size
- Facing type — RF / FF / RTJ
- Heat / lot number — for MTC traceability
Coating & Surface Finish Options
| Coating Type | Standard | Application | Lead Time |
|---|---|---|---|
| Mill Finish / Black Paint | Per standard | General process service | In Stock |
| Yellow Zinc Chromate Primer | — | Corrosion protection in transit | In Stock |
| Hot-Dipped Galvanised (HDG) | ASTM A123 | Plumbing & utility service | 3–5 days |
| Two-Coat Epoxy Paint | — | Offshore & chemical plant | 1–2 weeks |
Testing & Inspection Procedure
All ASTM A105 Weld Neck Flange supplied by BB Infras undergo a multi-stage inspection and testing process before dispatch:
| # | Test / Inspection | Standard / Method | Acceptance |
|---|---|---|---|
| 1 | Chemical Composition (OES) | ASTM E415 | Per ASTM A105 Table 1 |
| 2 | Tensile & Yield Strength | ASTM E8 | ≥485 MPa min / ≥250 MPa min |
| 3 | Elongation | ASTM E8 | ≥22% min |
| 4 | Hardness (HB) | ASTM E10 | Per standard max |
| 5 | Hydrostatic Test | ASTM A105 / ASME B31.3 | Leak-free at test pressure |
| 6 | Dimensional Inspection | ASME B16.5 | Within tolerance |
| 7 | Visual & Surface | ASTM A530 / MSS SP-55 | Free from defects |
| 8 | Ultrasonic Testing (UT) | ASTM E213 (on request) | No sub-surface defects |
| 9 | PMI (XRF) | ASTM E1476 (on request) | Grade confirmation |
Storage & Handling Guidelines
- Store on wooden dunnage or pipe racks — never directly on concrete to avoid moisture-induced corrosion.
- Stack with appropriate separators; observe safe stack heights to prevent deformation.
- Apply plastic end caps or plugs to all open ends to prevent ingress of moisture, dust and insects.
- Keep material dry and ventilated; store under cover in humid or coastal climates.
- Use nylon slings or padded lifting hooks — never bare wire rope directly on surface.
- For long-term storage (>6 months), re-apply protective oil coating or wrap with VCI (Vapour Corrosion Inhibitor) film.
- Identify items with heat number tags throughout storage for full MTC traceability.
Downloads & Technical Resources
Request product documentation from our technical team. Available on enquiry:
Contact our technical team with your enquiry details and we will share the relevant document within 24 hours.
ASTM A105 Weld Neck Flange Supplier in India
BB Infras supplies ASTM A105 Weld Neck Flange to customers across India from our Mumbai stockyard. We serve all major industrial hubs — refineries in Jamnagar and Haldia, petrochemical clusters in Dahej and Panipat, shipyards in Kochi and Visakhapatnam, and fabrication workshops across Pune, Rajkot, Surat and Coimbatore — with same-day quotation and fast dispatch.
View all cities we supply ▾
ASTM A105 Weld Neck Flange Exporter – Countries We Ship To
BB Infras exports ASTM A105 Weld Neck Flange to 80+ countries with complete export documentation — Certificate of Origin, Material Test Certificate, Packing List, Bill of Lading and Fumigation Certificate. We are a trusted exporter to UAE, Saudi Arabia, Qatar, Oman and Kuwait in the Middle East; to Singapore, Malaysia, Indonesia and Vietnam in Southeast Asia; to South Africa, Nigeria and Kenya in Africa; and to the USA, UK, Germany and Netherlands in Europe and North America.
View all export countries ▾
Frequently Asked Questions
Get the best price for ASTM A105 Weld Neck Flange
Talk to our sales team — available Mon–Sat, 9 AM – 7 PM IST. Same-day quotes.
Contact Us Today +91-9152677155People Also Ask
What pressure classes are available for ASTM A105 Weld Neck Flange?
ASTM A105 Weld Neck Flange is available in 150#, 300#, 600#, 900#, 1500# and 2500# per ASME B16.5. For NPS > 24", ASME B16.47 Series A/B applies.
What facing options are available?
Available facings: Raised Face (RF), Flat Face (FF) and Ring Type Joint (RTJ). RF is the most common for general service.
What is the tensile and yield strength of ASTM A105?
Per ASTM A105: minimum tensile is 485 MPa min and minimum yield is 250 MPa min. Forging heat treatment normalises the material to achieve these values.
Do ASTM A105 flanges need PWHT after welding?
PWHT requirements depend on wall thickness and service per ASME B31.3 Section 331. For carbon steel flanges, PWHT typically applies for wall thickness above 19 mm or as specified by the engineer.
What is the price of ASTM A105 Weld Neck Flange in India?
Prices vary by size, pressure class, quantity and market rates. Contact BB Infras for a firm quotation from our Mumbai stockyard.
Authoritative Standards Referenced
| Standard | Issuing Body | Scope |
|---|---|---|
| ASTM A105 / ASME SA105 | ASTM / ASME | Material specification for ASTM A105 |
| ASME B16.5 | ASME | Pipe flanges and flanged fittings — NPS ½" – 24" |
| ASME B16.47 | ASME | Large diameter steel flanges — NPS 26" – 60" |
| EN 10204:2004 | CEN | Metallic products — types of inspection documents (3.1 MTC) |
| NACE MR0175 / ISO 15156 | NACE/ISO | Materials for H₂S service in oil and gas production |
